Spherical Niobium (Nb) Powder

Product Code : 3D-Nb-CU-PO1

Spherical Niobium (Nb) powder has the characteristics of high purity, low oxygen, high sphericity, smooth surface, no satellite, and uniform particle size distribution. Nb, as the lightest refractory metal, has the characteristics of high melting point, high-temperature strength and specific strength, no radioactivity, and so on. Spherical niobium powder is suitable for laser/electron beam augmentation, thermal isostatic pressing, laser cladding, thermal spraying, cold spraying, and so on.

Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.

Product Product Code Purity Size Contact Us
Spherical Niobium (Nb) Powder 3D-Nb-CU-PO1 Customize 0-15μm
Spherical Niobium (Nb) Powder 3D-Nb-CU-PO2 Customize 15-53μm
Spherical Niobium (Nb) Powder 3D-Nb-CU-PO3 Customize 45-105μm
Spherical Niobium (Nb) Powder 3D-Nb-CU-PO4 Customize 75-150μm
Spherical Niobium (Nb) Powder 3D-Nb-CU-PO5 Customize Customize

Niobium Powder Synonyms

Niobium particles, Niobium microparticles, Niobium micropowder, Niobium micro powder, Niobium micron powder, Niobium submicron powder, Niobium sub-micron powder

Spherical Niobium Powder Particle Size

0-15μm, 5-25μm, 15-45μm, 15-53μm, 45-75μm, 45-105μm, 75-150μm. (Various granularities can be customized according to customer requirements)

Spherical Niobium Powder Particle Size Description

● 0-15μm (D10=3~5μm, D50=6~10μm, D90=12~14μm)

● 5-25μm (D10=5~10μm, D50=15~20μm, D90=20~25μm)

● 15-45μm (D10=15~20μm, D50=25~30μm, D90=35~40μm)

● 15-53μm (D10=15~20μm, D50=25~35μm, D90=45~50μm)

● 45-75μm (D10=45~55μm, D50=55~65μm, D90=70~75μm)

● 45-105μm (D10=50~60μm, D50=75~85μm, D90=95~105μm)

● 45-150μm (D10=55~70μm, D50=110~120μm, D90=140~150μm)

● 75-150μm (D10=80~90μm, D50=110~125μm, D90=135~150μm)

Spherical Niobium (Nb) Powder

Spherical Niobium (Nb) Powder

Spherical Niobium Powder Chemical Composition

Chemical Composition - by ICP-AES
Value (%)≥99.98<0.003<0.005<0.001<0.005<0.002<0.002<0.002
Gas Impurities
Value (%)</= 0.01</= 0.002</= 0.06</= 0.003

Density (g/cm3)Hall Flow Rate (s/50g)
Apparent DensityTap DensityValue
>4.5>5.5</= 15.0

Spherical Niobium Powder Characteristics

High purity (≥99.9%), low oxygen (≤600ppm), high sphericity (≥98%), smooth surface, no satellite spheres, uniform particle size distribution, and excellent flow properties (≤15.0s/50g), and high bulk density (≥4.5g/cm3) and tap density (≥5.5g/cm3).

Spherical Niobium Powder Applicable processes

Laser/electron beam additive manufacturing (SLM/EBM, 3D printing), laser direct deposition (DLD), powder hot isostatic pressing (HIP), metal injection molding (MIM), powder metallurgy (PM), laser cladding ( LC), and other processes.

Spherical Niobium Powder Application

Niobium is the lightest refractory metal. It has the characteristics of high melting point, high-temperature strength and specific strength, and no radioactivity. It is the preferred thermal protection material and structural material for aerospace engines. Radiofrequency plasma spheroidized niobium powder has the characteristics of high sphericity, good fluidity, high purity, large loose packing density, the full internal density of the particles, and no hollow powder. It is widely used in palladium materials, vacuum coating, thermal spraying, coating, cold spraying, and other fields.

Packing of Spherical Niobium Powder

Standard Packing:

Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.

ATTs’Spherical Niobium Powder is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.

Chemical Identifiers

Linear FormulaNb
MDL NumberMFCD00011126
EC No.231-113-5
Beilstein/Reaxys No.N/A
Pubchem CID23936
InchI IdentifierInChI=1S/Nb
