Product Code : ME-BeCu-5N-SF
Beryllium copper tube is a type of metal tube made from an alloy of copper and beryllium. The precise amount of beryllium in the alloy varies, but typically ranges from 0.5 to 3% by weight. The alloy has a unique combination of properties that make it ideal for a range of applications.
Beryllium copper tubes are known for their high strength, ductility, and electrical conductivity. They also exhibit excellent resistance to corrosion, wear, and fatigue, making them ideal for use in high-stress applications that require exceptional mechanical or electrical properties. The tubes are typically manufactured using a process called extrusion, where a metal billet is forced through a die to create the desired tube shape.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Information
Beryllium copper tube is a type of metal tube made from an alloy of copper and beryllium. The precise amount of beryllium in the alloy varies, but typically ranges from 0.5 to 3% by weight. The alloy has a unique combination of properties that make it ideal for a range of applications.
Beryllium copper tubes are known for their high strength, ductility, and electrical conductivity. They also exhibit excellent resistance to corrosion, wear, and fatigue, making them ideal for use in high-stress applications that require exceptional mechanical or electrical properties. The tubes are typically manufactured using a process called extrusion, where a metal billet is forced through a die to create the desired tube shape.
Synonyms
Copper beryllium; Copper-beryllium; BeCu; CuBe; CuBe2; beryllium bronze; spring copper, C17200, C17300, Alloy 25, C17000, NIST SRM 458, NIST SRM 459, NIST SRM 460, Berylco 25, 33/25, 14, 8, 7, AMS 4651, AMS 4725, ASTM B194, ASTM B196, ASTM B197, ASTM B570, MIL C-21657, SAE J461, SAE J463, CAS 12232-11-0, 20C, 10C, 70C, 165C, 275C
Typical Applications:
Beryllium copper tubes are commonly used in electrical and electronic systems due to their high electrical conductivity and resistance to corrosion. They are also used in a range of other industries, including aerospace and defense, automotive, and medical systems. Applications include heat exchangers, pneumatic and hydraulic systems, conductive springs, and antennas.
It is important to note that beryllium is a toxic substance, and proper handling and safety precautions must be taken during the manufacturing and use of beryllium copper tubes. Workers should be trained to handle the material safely, and suitable personal protective equipment should be used to minimize exposure to beryllium dust or fumes.
Beryllium (Be) Foil Specifications
| Compound Formula | BeCu |
| Molecular Weight | 72.56 |
| Appearance | Bronze-colored solid in various forms (tubes, rods, sheets, strips, wires, sputtering targets) |
| Melting Point | 865 - 955 °C |
| Boiling Point | N/A |
| Density | 8.25-8.36 g/cm3 |
| Solubility in H2O | Insoluble |
| Poisson's Ratio | 0.3 |
| Specific Heat | 0.420 J/g°C |
| Tensile Strength | 1280 - 1480 MPa (ultimate); 965 - 1205 MPa (yield) |
| Thermal Conductivity | 105 - 130 W/m-K (20 °C) |
| Thermal Expansion | 16.7 μm/m°C (20-100 °C) |
| Exact Mass | 71.942 g/mol |
| Monoisotopic Mass | 71.942 g/mol |
Beryllium Copper Tube Packaging
Standard Packing: Sealed bags. Special package is available on request.
Our beryllium plates are carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Chemical Identifiers
| Linear Formula | Be-Cu |
| MDL Number | MFCD01320550 |
| EC No. | N/A |
| Pubchem CID | 57419137 |
| IUPAC Name | beryllium; copper |
| SMILES | [Be].[Cu] |
| InchI Identifier | InChI=1S/Be.Cu |
| InchI Key | DMFGNRRURHSENX-UHFFFAOYSA-N |
