Product Code : AL-TaWHf -W10-CU
Tantalum tungsten hafnium alloy is made from a certain amount of tungsten and hafnium added to the base of tantalum. tantalum tungsten hafnium alloy has excellent thermal stability and high creep strength in the temperature range from 93 ˚C to 1426˚C. Since the year of 1960 to 1963, the United States successfully developed Ta10W - 2.5 Hf - 0.01Zr-0.1Nb - 0.02Mo alloy. Tantalum tungsten hafnium alloy is divided into solid - soluble strengthening alloy and dispersion strengthened alloy by reinforcement schedule.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Product | Product Code | Purity | Size | Contact Us |
Product Information
Tantalum tungsten hafnium alloy is made from a certain amount of tungsten and hafnium added to the base of tantalum. tantalum tungsten hafnium alloy has excellent thermal stability and high creep strength in the temperature range from 93 ˚C to 1426˚C. Since the year of 1960 to 1963, the United States successfully developed Ta10W - 2.5 Hf - 0.01Zr-0.1Nb - 0.02Mo alloy. Tantalum tungsten hafnium alloy is divided into solid - soluble strengthening alloy and dispersion strengthened alloy by reinforcement schedule.
Synonyms
T - 122
Tantalum tungsten hafnium alloy Specification
Dimensions
Per your request or drawing
We can customized as required
Tantalum tungsten hafnium Alloy Products
| Materials | Ta-10W-2.5Hf-0.1Zr-0.1Nb-0.02Mo |
| Plate | √ |
| Sheet | √ |
| Strip | √ |
| Rod | √ |
| Powder | √ |
| Tube | √ |
Other: Spherical Tantalum Tungsten hafnium Alloy Powder, Tantalum tungsten hafnium alloy crucibles, Tantalum-tungsten hafnium alloy nuts, Tantalum-tungsten hafnium alloy bolts, Tantalum-tungsten hafnium alloy heating elements, and Tantalum-tungsten hafnium alloy shielding screens.
Properties（Theoretical）
| Products | T-122 |
| Nominal composition(wt%) | Ta-10W-2.5Hf-0.1Zr-0.1Nb-0.02Mo |
| Density/g·cm-3 | 16.79 |
| Melting Point/˚C | 3028 |
| Coefficient of Line-Expansion/10-6K-1 | 4.2 (1649˚C) |
| Recrystallization Temperature/˚C | 1538 - 1649 |
| Annealing Temperature/˚C | 1093 - 1316 |
| Extension of Brittle Transition Temperature/˚C | - 196 |
| Modulus of Elasticity/MPa | 203 890 |
| Tensile Strength/MPa | 703 (21˚C) |
| Yield Strength/MPa | 773 (21˚C) |
| Elongation/% | 30 (21˚C) |
| Material Form | Rod, Plate |
Packing of Tantalum Tungsten hafnium Alloy Products
Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.
ATTs’Tantalum Tungsten hafnium Alloy Products is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
