Tungsten rolled products available from us, including tungsten plate, sheet, and foil with many options on width, length, and thickness. Pure Tungsten rolled products are fabricated from pressed and sintered powder metallurgy ingot. ATT provide tungsten plate with purity W≥99.95%, which are widely used in ion implantation, sputtering and coating, medical CT, electronics and vacuum equipment.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
Product Information
Tungsten rolled products available from us, including tungsten plate, sheet, and foil with many options on width, length, and thickness. Pure Tungsten rolled products are fabricated from pressed and sintered powder metallurgy ingot. ATT provide tungsten plate with purity W≥99.95%, which are widely used in ion implantation, sputtering and coating, medical CT, electronics and vacuum equipment.
We provide tungsten sheets with various dimensions to meet your various needs.
Synonyms
GF22706210, GF01295502, GF30443554, GF33990273, GF38415023, 276324, 10403, 10406, 10407, 42233
Specifications Of Tungsten Plate
| Product | Tungsten Plate |
| Purity | W≥99.95% |
| Size | T(1.5-25)*W(150-300)*L(200-800) mm |
| Density | 19.2g/ cm3 |
| Process | Rolling |
| Surface | Black Ground alkali wash |
Tungsten Polished Plate Dimensions (Max, mm)
| Thickness | Width | Length |
| 1.5-2.0 | 150 | 200 |
| 2.0-3.0 | 200 | 250 |
| 3.0-4.0 | 250 | 600 |
| 4.0-6.0 | 300 | 600 |
| 6.0-8.0 | 300 | 800 |
| 8.0-10.0 | 300 | 750 |
| 10.0-14.00 | 200 | 650 |
| >14.0 | 200 | 500 |
We Offer Competitive Pricing And Great Lead Times On All Our Materials, And We're Capable Of Supplying Custom Materials Per Any Specs/Drawings You Provide Us With.
Applications Of Tungsten Plate
Tungsten plates can be used as:
* Parts of Electric Light Sources and Electron Tubes;
* Medical Facilities;
* To Heat Elements of High-Temperature Furnaces;
* Structures of High-Temperature Furnaces;
* Tungsten sputtering target.
Packaging Of Tungsten Plate
Standard Packing:
Sealed bags in carton boxes. Special package is available on request.
ATTs’ Tungsten Plate is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Chemical identifier
| Linear Formula | W |
| MDL Number | MFCD00011461 |
| EC No. | 231-143-9 |
| Beilstein/Reaxys No. | N/A |
| Pubchem CID | 23964 |
| SMILES | [W] |
| InchI Identifier | InChI=1S/W |
| InchI Key | WFKWXMTUELFFGS-UHFFFAOYSA-N |
