Product Code : ME-Ta-99.995%-CR
Tantalum Crucible is made of high-purity tantalum metal, including seamless and welded tantalum crucible. Due to its excellent corrosion resistance properties, tantalum crucible is the ideal product for melting corrosive materials. Tantalum crucibles are mainly used for the melting of corrosive materials and the growth of crystals.
Pure Tantalum Crucible is available in 99.95% to 99.999% purity. All Tantalum Crucible follow ASTM.
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
|Product||Product Code||Purity||Size||Contact Us|
Tantalum Crucible is made of high-purity tantalum metal, including seamless and welded tantalum crucible. Seamless Tantalum Crucible is made by a seamless method that will yield a product meeting the requirements of the specification. Welded Tantalum Crucible is made from a flat-rolled product by an automatic or semiautomatic fusion welding process with no addition of filler metal.
Due to its excellent corrosion resistance properties, tantalum crucible is the ideal product for melting corrosive materials. Tantalum crucibles are mainly used for the melting of corrosive materials and the growth of crystals. Pure Tantalum Crucible is available in 99.9% to 99.999% purity. All Tantalum Crucible follow ASTM.
Specifications Of Tantalum Crucible
|Size||10-500mm OD x 10-500mm H, Customized|
|Material||Ta≥99.95% (R05200, R05400)|
|Surface||Finish turning, Polishing|
Dimensions of Tantalum Crucible
|Diameter (mm)||Wall Thickness (mm)||Height (mm)|
|10 ~ 30||1 ~ 3||10 ~ 500|
|30 ~ 50||2 ~ 10|
|50 ~ 100||3 ~ 15|
|100 ~ 150||3 ~ 15|
|150 ~ 200||5 ~ 20|
|200 ~ 300||8 ~ 20|
|300 ~ 400||8 ~ 30|
|400 ~ 450||8 ~ 30|
|450 ~ 500||8 ~ 30|
ATT supply all kinds of Tantalum crucibles and other Tantalum parts (including heaters, heat insulation screens, sheets and supports, etc.) used in the process of sapphire growth and rare-earth melting and we can manufacture the products according to customers’ drawings and specific requirements.
Tantalum Crucible Properties
|Melting Point||3017 °C|
|Boiling Point||5458 °C|
|Density||16.69 g/cm3 (20 °C)|
|Solubility in H2O||N/A|
|Crystal Phase / Structure||α: body-centered cubic (bcc) / β: tetragonal|
|Electrical Resistivity||131 nΩ·m (20 °C)|
|Heat of Fusion||36.57 kJ/mol|
|Heat of Vaporization||753 kJ/mol|
|Specific Heat||140 J/kg·K|
|Thermal Conductivity||57.5 W/m·K|
|Thermal Expansion||6.3 µm/m·K|
|Vickers Hardness||870–1200 MPa|
|Young's Modulus||186 GPa|
Chemical Composition for Tantalum Crucible
|Brand||Main component||Impurity content(≤)|
Applications of Tantalum Crucible
* In laboratory equipment.
* As a substitute for platinum.
* In manufacturing superalloys and electron-beam melting.
* In metallurgical, machinery processing, glass, and ceramic industries.
Packaging of Tantalum Crucible
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 440 gallon liquid totes Special package is available on request.
ATTs’ Tantalum Crucible is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
